PSC115

Small Diameter, flexible power

• Small diameter and flexible due to the special cable structure
• Parallel controls for active speakers via power line and Analog-signal via audio cable
• Very good paired shielding of the audio cable due to dense spiral copper shielding and additional AL/PT-foil

Send email to us

Product Detail

Product Tags

Applications

• Controls for active speakers
• Analog audio multipair with power supply

Cable Colour

• Black

Technical Data

Order Code	PSC115
Total jacket, diameter	PVC 12.0 mm

Power Cable
AWG	16
No. of power conductors	3 x 1.50 mm²
Copper strand per conductor	192 x 0.10 mm
Insulation material	PVC

Signal Cable
Jacket, diameter	PVC 4.0 mm
AWG	24
No. of inner conductors	2 x 0.22 mm²
Copper strand per conductor	28 x 0.10 mm
Insulation material	LDPE
Shielding	48 x 0.1mm+ Aluminum-plastics tape

Temperature range	min. -20 °C
Temperature range	max. +70 °C
Packaging	100m roll

Electrical Data

	Power Cable	Signal Cable
Capac. Cond./cond.	123 pF/m	67 pF/m
Capac. Cond./shield.	n/a	138 pF/m
Cond. resistance	12 mΩ/m	82 mΩ/m
Shield resistance	n/a	48 mΩ/m
