6.3mm Plug
Pure series 6.3mm Plug ( 1/4″TS )
PURE SERIES 6.3mm MONO PLUG
Features
• The best partner of Pureplug
• Pure brass contact and more thick sleeve tube 0.5mm supply the more pure sound
• Reliable chuck type cable strain-relief clamp fix the cable more tight and up
to 7.5mm cable
• Classic and simple design with patents protecting
• Four colors suitable for different style cables
• Patent protected
Engineering Drawing
Technical Data
| Title | ||
| Housing | Zinc alloy diecast | |
| Insulation | PBT 15% GR | |
| Contacts | Brass | |
| Contacts plating | Gold | |
| Bushing | PA 30% GR & TPE | |
| Order Code | Description | |
| PJ2X-SG | 6.3mm mono plug, Satin nickel housing, Gold plated contacts | |
| PJ2X-GG | 6.3mm mono plug, Rifle color housing, Gold plated contacts | |
PURE SERIES 6.3mm MONO PLUG
Features
• The best partner of Pureplug
• Pure brass contact and more thick sleeve tube 0.5mm supply the more pure sound
• Reliable chuck type cable strain-relief clamp fix the cable more tight and up to 7.5mm cable
• Classic and simple design with patents protecting
• Four colors suitable for different style cables
• Patent protected
Engineering Drawing
Technical Data
| Title | ||
| Housing | Zinc alloy diecast | |
| Insulation | PBT 15% GR | |
| Contacts | Brass | |
| Contacts plating | Gold | |
| Bushing | PA 30% GR & TPE | |
| Order Code | Description | |
| PJ2RX-SG | 6.3mm mono plug, Satin nickel housing, Gold plated contacts | |
FAQ
1. What’s the design concept for them?
The PURE series connectors are designed and developed for the high end user who is very sensitive to sound quality.
And PJ2X / PJ2RX / PJ3X are the best partners of Pure plug, which can match Pure plug in an instrument cable. Meanwhile, they are also high-end 6.3mm plug for separate use.
2. What’s the material of contact?
The complete contact is 100% brass with thicker 0.5mm for the thickness of sleeve tube, which makes signal transmission more stable and sound purer. And it has excellent 24K 50nm gold-plating, which reduces the loss of sound quality.
3. What the maximum cable diameter does it suit?
The reliable chuck type cable strain relief clamp can fix the cable more tight and up to 7.5mm.
4. What’s the advantage of welding lug?
They have a 100% brass welding lug with 50nm gold-plated and an extended drain wire welding lug with 50nm gold plated, which ensure excellent conductivity, and more convenient welding.
5. What are the applications for them?
They can be used in large stage performances, radio stations, business shows, artistic performances and so on.
And they can be compatible with devices that have electric pickups, like electric bass, electric guitar, electric piano, drum set, etc…
6. Can we do my own logo for them?
Sorry, our Pure series plugs all have ROXTONE logo engraved on the shell and have appearance patent protecting, which can only be provided with ROXTONE logo.
7. What is the MOQ requirement for them?
Normally, we require one carton QTY for each item at least.
The MOQ for PJ2X / PJ2RX / PJ3X is 400 pcs each item.
8. What’s the lead time?
It’s mainly based on the order quantities and also our production capacity, our standard lead time is 30-50day, we will confirm the lead time with you after receiving your order.
