6.3mm Plug
Pure 6.3mm Mono Plug ( 1/4″TS )
6.3mm MONO PLUG
Features
• Avoid pops and squeals automatically when changing the instruments under load
• Patents protected with PURE CORE Technology
• Pure bronze and mechanical structure switch system guarantee the longer lifetime using beyond 150,000 mating cycles
• Pure brass contact and more thick tube 0.5mm s sleeve upply the more pure sound
• Reliable chuck type cable strain-relief clamp fix the cable more tight and up to 7.5mm cable
• Classic and simple design with patents protecting
• Three colors suitable for different style cables
Patents#
Invention
Utility model
Appearance
Appearance
201810207321.7
201820344006.4
201830506386.2
201830506384.3
Engineering Drawing
Technical Data
| Title | ||
| Housing | Zinc alloy diecast | |
| Insulation | PBT 15% GR | |
| Contacts | Brass | |
| Contacts plating | Gold | |
| Bushing | PA 30% GR & TPE | |
| Order Code | Description | |
| PJ2X-SG-PURE | 6.3mm mono plug, Satin nickel housing, Gold plated contacts | |
| PJ2X-GG-PURE | 6.3mm mono plug, Rifle color housing, Gold plated contacts | |
6.3mm MONO PLUG
Features
• Avoid pops and squeals automatically when changing the instruments under load
• Patents protected with PURE CORE Technology
• Pure bronze and mechanical structure switch system guarantee the longer lifetime
using beyond 150,000 mating cycles
• Pure brass contact and more thick tube 0.5mm s sleeve upply the more pure sound
• Reliable chuck type cable strain-relief clamp fix the cable more tight and up to 7.5mm cable
• Classic and simple design with patents protecting
• Three colors suitable for different style cables
Engineering Drawing
Technical Data
| Title | ||
| Housing | Zinc alloy diecast | |
| Insulation | PBT 15% GR | |
| Contacts | Brass | |
| Contacts plating | Gold | |
| Bushing | PA 30% GR & TPE | |
| Order Code | Description | |
| PJ2RX-SG-PURE | 6.3mm mono plug, Satin nickel housing, Gold plated contacts | |
FAQ
1. What’s the main feature of Pure plug compared to the other 6.3mm plug?
Our Pure plug can avoid pops and squeals automatically when changing the instruments under load.
2. What problem can Pure plug solve?
When playing and using expensive AMP, anyone doesn’t want pops caused by accidentally dropping the cable, which is critical strike for AMP, and will lead to irreversible damage to the small bulb.
Just change a guitar or effect pedal, the Power Amp will experience multiple high voltage shocks. Using Pure plug cable can replace the STANDBY on Amp, you only need to unplug the cable and replace the device, no longer need to turn on/off the STANDBY switch frequently.
3. How does Pure plug achieve no pops & squeals?
Pure plug has “Pure Core Tech” Noise-free system. The pure bronze and mechanical structure switch system guarantee the longer lifetime using beyond 150,000 matching cycles, no pops & squeals while plug & unplug.
4. Is there any matters needing attention?
Pure plug only needs to be used at one end and must connect with the instrument. If connected with AMP, it may damage the equipment.
5. What is the material for contact of Pure plug?
The Pure plug has 2.3mm 100% brass contact with 0.5mm thick sleeve tube that can supply more pure sound. And the contact is 24K 50nm gold-plated that can reduce loss of sound quality, ensure pure sound quality, prolong service life.
6. Can we customize our logo for Pure plug?
We have patents protected with PURE CORE Technology and appearance design, and Pure plug has ROXTONE logo engraved on the shell. So we can only offer ROXTONE logo Pure plug.
7. What cable do you recommend to assemble with Pure plug?
We have various instrument cables for choice, and for Pure plug, we recommend our high-end instrument cable GCX150, which has super low capacitance 56pf.
8. What is the MOQ requirement for Pure plug?
PJ2X-SG-PURE / PJ2X-BG-PURE / PJ2RX-SG-PURE / PJ2RX-BG-PURE requires 400 pcs each item at least.
