Cat Splitter System

Cat snake splitter & Cat splitter box

• Transfer multi-channel digital signals or analogue balanced signals
• Compact device, easy for storage and transportation
• Support 48V phantom power, directly transmit to an analog or digital console
• PS4F & PS4M compatible with PS4MD & PS4FD


Product Detail

Product Tags

CAT SPLITTER BOX

Order Code: PS4MD

PS4MD800
PS4MD-反800

Order Code: PS4FD

PS4FD800
PS4FD-反800

Features

• Used to connect a single shielded CAT5,5E,6,6A or 7 cable to transmit and receive multiple lighting consoles,microphones, musical instrument, speakers, and other audio signals for the compact convenience of transmitting multi-channel digital signals or analogue balanced signals.
• The extremely compact device, along with a roll of network cable, takes up little storage space and is easy to transport, assure to enjoy balanced digital or analog signal transmission and clear, high-quality sound in a variety of indoor and outdoor environments.
• Bidirectional passive device, supports 48V phantom power, can transmit directly to an analog or digital console.
• Designed accord to the highest professional standards, has flat frequency response, low THD and low noise.
• Ground lift button to switch the ground loop and eliminate the noise.
• Firm and durable metal structure, minimalist use, plug and play.
• Compatible with PS4M/PS4F cable splitter.

应用场景2

CAT SPLITTER BOX

Order Code: PS4F

PS4F800

Order Code: PS4M

PS4M800

Features

• Used to connect a single shielded CAT5,5E,6,6A or 7 cable to transmit and receive multiple lighting consoles, microphones, musical instrument, speakers, and other audio signals for the compact convenience of transmitting multi-channel digital signals or analogue balanced signals.
• The extremely compact device, along with a roll of network cable, takes up little storage space and is easy to transport, assure to enjoy balanced digital or analog signal transmission and clear, high-quality sound in a variety of indoor and outdoor environments.
• With 4pcs of 110Ω cables for wiring, black 3P gold pin XLR connectors with dust-proof covers.
• The cable is coded numerically to easily define different channels. Nylon braided jacket, wear and tear resistance under performance conditions.
• Bidirectional passive device, supports 48V phantom power, can transmit directly to an analog or digital console.
• Designed accord to the highest professional standards, has flat frequency response, low THD and low noise.
• Minimalist use, plug and play.
• Compatible with PS4MD/PS4FD cable splitter box.

应用场景1

FAQ

1. Which type cable shall I use for Cat Splitter System?
All shielded Cat5/Cat5e/Cat6/Cat6a and Cat7 cables are suitable for out Audio/DMX Extenders.

2. Does Cat Splitter System cause latencies?

No. This is a simple adapter, that doesn’t change the signal, read or use the signal other than any else cable. That’s why signals are transmitted without any delay or phase shift.

3. Can I use phantom power with Cat Splitter System?
Yes! Phantom power is applied to the signal wires only, not to common ground.  So there is no influence on other channels.  Please bear in mind, that a GND connection is required! (Which is recommended for audio applications anyway)

4. Is the whole Cat Splitter System compatible within itself?
Yes! All Cat Splitter System use the same pinout. So all items can be linked in every combination. We cannot guarantee compatibility to other manufacturers, but will be happy to help verifying whether your product matches our pinout.

5. Can I include Cat Splitter System into my IT Network?
No! Cat Splitter System just uses cat cables, but doesn’t match any structures of network technologies.

6. What is the maximum transmission distance these products can support?
These products are simple adapters, and the maximum transmission distance depends on the network cable you are using and sender, transmitter. We cannot directly define the maximum transmission distance.

7. What's the difference between PS4F PS4M and PS4FD PS4MD?
The main functions of the two types are similar.
But this box type (PS4FD PS4MD) has ground lift button to switch the ground loop and eliminate the noise, and more robust and durable than PS4F&PS4M.
And it's also smaller and easier to carry around.

8. What you required MOQ for them?
The MOQ for PS4F and PS4M is 40pcs, PS4FD and PS4MD is 24pcs.
